One command to a working ArcGIS app: the @arcgis/create CLI

Every framework worth using has a scaffolding command. React has one. Vue has one. Vite has one. For years, starting an ArcGIS Maps SDK for JavaScript project meant doing it the long way — scaffold a bare app, install three packages, guess at the CSS imports, discover the asset path problem in production. Esri closed that gap: @arcgis/create generates a working, SDK-wired project in one command, across seven templates.

This post covers what the CLI actually produces, how it differs from the CDN path, the one CSS behaviour that still catches people migrating from widgets, and the short list of things the template deliberately does not do for you — the gap between “it runs” and “it ships.”

Two ways in, and they solve different problems

Esri’s Get started guide now frames the decision cleanly. There is a CDN path and an npm path, and the honest answer to “which one” is that they are not competing — they serve different stages of work.

The current CDN entry point is version-pinned in the URL:

<!-- Load the ArcGIS Maps SDK for JavaScript from CDN -->
<script type="module" src="https://js.arcgis.com/5.1/"></script>

What the CLI does

The @arcgis/create tool runs through either npm init or npx. Run it with no arguments and it prompts you interactively:

# interactive — either form works
npm init @arcgis
npx @arcgis/create

Or skip the prompts entirely with flags, which is what you want in a documented setup script or a repeatable team workflow:

# CLI options:
#   -n, --name <name>          Name of the project
#   -t, --template <template>  Template to use

npx @arcgis/create -n my-arcgis-app -t vite

Seven templates ship today, and the naming is exactly what you would guess:

If you would rather read the templates before you run anything, they live in the public Esri/jsapi-resources repository. Esri notes these demonstrate working with the core API, components, OAuth, and Calcite — the OAuth template in particular is worth reading before you hand-roll an auth flow.

What a generated project contains

Under the hood the templates install the same three packages you would install by hand:

npm install @arcgis/map-components @arcgis/core @esri/calcite-components

That split matters and is worth internalising. @arcgis/core is the core API — layers, geometry, renderers, query. @arcgis/map-components is one of six component libraries the SDK now ships (Map, Charts, AI in beta, Embeddable, Coding, and Common). @esri/calcite-components is Esri’s Calcite Design System, which supplies the surrounding UI shell.

Components are registered by importing them, which is easy to miss if you are used to widgets:

import "./index.css";

import "@arcgis/map-components/components/arcgis-map";
import "@arcgis/map-components/components/arcgis-zoom";
import Graphic from "@arcgis/core/Graphic.js";

const viewElement = document.querySelector("arcgis-map");

// Wait for the view to be ready before adding functionality
viewElement.addEventListener("arcgisViewReadyChange", () => {
  const pointGraphic = new Graphic({ geometry: point, symbol: markerSymbol });
  viewElement.graphics.add(pointGraphic);
});

The import is not decoration — it registers the custom element with the browser’s CustomElementRegistry. Forget it and <arcgis-map> renders as an inert unknown element with no error in the console. That silence is the single most common “why is my map blank” in a component-based project.

The CSS trap that still catches people

This is the detail worth the price of admission. When you use components via npm, the SDK’s component styles and Calcite styles are loaded for you. You only need enough app CSS to give the map a box with height:

/* index.css */
html,
body {
  height: 100%;
  margin: 0;
}

But if any part of your app still uses widgets, or programmatically constructs a MapView or SceneView instead of using the Map or Scene component, you must still import the core API stylesheet yourself:

/* only needed if you use widgets or a programmatic MapView/SceneView */
@import "@arcgis/core/assets/esri/themes/light/main.css";

The failure mode is unusually confusing: a half-migrated app looks almost right — the map draws, the components look fine — and only the remaining widgets render unstyled. It reads like a broken widget rather than a missing stylesheet.

What the template does not do for you

A generated project runs. That is not the same as ready to ship. Five things we add on every ArcGIS project before it is allowed near a client environment:

1. Move the API key out of source. Templates put a key where you can find it. Production reads it from an environment variable and the key itself is scoped to the referrers and services the app actually needs — nothing more.
2. Pin the dev server port. API key referrer restrictions and OAuth redirect URIs are origin-bound. A dev server that silently picks a new port when the old one is busy will fail auth in ways that look like credential problems. Fix the port; make it strict.
3. Decide the asset strategy early. The default pulls SDK assets from Esri’s CDN. Disconnected or air-gapped deployments need local assets — see Esri’s working with assets guide. Retrofitting this after the fact is unpleasant.
4. Replace the default chrome. A template app looks like a template app. If the map is your product, the UI around it needs to be designed — Calcite theming, your typography, your colours, real cartography.
5. Add accessibility and performance budgets. Keyboard reachability for every map control, contrast that passes WCAG, and a hard ceiling on initial bundle size. Map apps regress on all three quietly.

References

• Get started — ArcGIS Maps SDK for JavaScript (CDN and npm paths, @arcgis/create usage)
• Using the SDK in a Vite JavaScript app — installation, CSS, component imports
• ArcGIS Maps SDK for JavaScript release notes
• Components transition plan — migrating from widgets
• Working with assets — local assets and disconnected deployments
• Esri/jsapi-resources — application templates (core API, components, OAuth, Calcite)
• @arcgis/create on npm
